DESCRIPTION
The ZONESUN ZS-PXF10 is a high-efficiency 10-head rotating perfume filling machine engineered for precision and speed. Utilizing negative pressure vacuum filling, it ensures consistent liquid levels across every bottle, minimizing waste and maximizing output. All contact parts are made from 316L stainless steel, while the body features durable 304 stainless steel construction—ideal for maintaining hygiene in fragrance production. With a filling range of 5–1000ml and a speed of up to 1,200 bottles per hour, this mobile, easy-to-adjust system is perfect for perfume factories and cosmetic bottling lines.
📋 Technical Specifications
| Parameter | Specification |
|---|---|
| Model | ZS-PXF10 |
| Air Source | 0.4–0.6 kg/min |
| Filling Volume | 5–1000 ml |
| Filling Speed | 1,200 bottles/hour |
| Filling Principle | Vacuum (negative pressure) filling |
| Filling Heads | 10 pcs |
| Filling Accuracy | ≥99.7% |
| Weight | 445 kg |
| Machine Dimensions (L×W×H) | 1170 × 1100 × 2140 mm |
Key Features
- 10-Head Rotary System — Fills 10 bottles simultaneously for maximum throughput
- Vacuum Filling Principle — Negative pressure ensures consistent liquid levels and zero overflow
- High Filling Accuracy — ≥99.7% accuracy, minimizing product waste
- 316L Stainless Steel Contact Parts — Corrosion-resistant, hygienic, and compatible with alcohol-based fragrances
- Wide Filling Range — 5–1000ml, suitable for various bottle sizes
- Mobile & Easy to Adjust — Wheeled base for flexible floor placement and quick changeover
